Frame
OCLV Mountain Carbon, IsoSpeed, tapered head tube, Knock Block, internal control routing, balanced post-mount brake, Boost148
Fork
RockShox Judy SL, Solo Air spring, TurnKey lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 100 mm travel
Max compatible fork travel
120mm (533mm axle-to-crown)
Hub front
Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle
*Hub rear
Size: S, M, M/L, L, XL, XXL
Bontrager sealed bearing, Boost148
Size: S, M, M/L, L, XL, XXL
Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru axle
Rim
Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve
Tyre
Bontrager XR2 Team Issue, Tubeless-Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29 x 2.20"
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
Sealant
Bontrager TLR sealant, 180 ml/6 oz
Max tyre size
Frame: 29x2.40", Fork: See manufacturer
Shifter
Shimano Deore M6100, 12-speed
Rear derailleur
Shimano Deore M6100, long cage
*Crank
Size: S, M
Shimano MT511, 30T steel ring, 52 mm chainline, 170 mm length
Size: M, M/L, L, XL, XXL
Shimano MT511, 30T steel ring, 52 mm chainline, 175 mm length
Bottom bracket
Shimano MT500, 92 mm, PressFit
*Cassette
Size: S, M, M/L, L, XL, XXL
Shimano Deore M6100, 10-51, 12-speed
Size: S, M, M/L, L, XL, XXL
SunRace CSMZ800 11-51, 12-speed
Chain
Shimano Deore M6100, 12-speed
Max. chainring size
1x: 36T, min 30T
*Saddle
Size: S, M, M/L, L, XL, XXL
Bontrager Arvada, steel rails, 138 mm width
Size: S, M, M/L, L, XL, XXL
Bontrager Verse Comp, steel rails, 145 mm width
*Seatpost
Size: S
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Size: M
Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm length
Size: M/L, L, XL, XXL
Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
*Handlebar
Size: S, M, M/L
Bontrager Comp, alloy, 31.8 mm, 5 mm rise, 720 mm width
Size: L, XL
Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 750mm width
Size: XXL
Bontrager Line, alloy, 35 mm, 15 mm rise, 750 mm width
Grips
Bontrager XR Trail Comp, nylon lock-on
*Stem
Size: S, M
Bontrager Rhythm Comp, 31.8mm, Knock Block, 0-degree, 60 mm length
Size: M, M/L
Bontrager Rhythm Comp, 31.8 mm, Knock Block, 0-degree, 70 mm length
Size: L, XL
Bontrager Rhythm Comp, 31.8mm, Knock Block, 0-degree, 80 mm length
Size: XXL
Bontrager Kovee Pro, 35 mm, Knock Block, Blendr-compatible, 13-degree, 90 mm length
Size: XXL
Bontrager Elite, 35 mm, 0-degree, 90 mm length
Brake
Shimano MT200 hydraulic disc
*Brake rotor
Size: S, M, M/L, L, XL, XXL
Shimano RT26, 6-bolt,160 mm
Size: L, XL, XXL
Shimano RT26, 6-bolt,180 mm
Brake Set
Shimano MT200 hydraulic disc
Rotor size
Max brake rotor sizes - Frame: 180mm, Fork: see fork manufacturer
Weight
M - 12.20 kg / 26.9 lbs (with TLR sealant, no tubes)
Weight limit
This bike has a maximum total weight limi
