Frame
OCLV Mountain Carbon, internal storage, tapered head tube, Knock Block 2.0, internal guided routing, downtube guard, magnesium rocker link, Mino Link, ABP, Boost148, 120 mm travel
Fork
RockShox Pike Ultimate, DebonAir spring, Charger 3 RC2 damper, 44 mm offset, Boost110, Maxle Stealth, 130 mm travel
Shock
RockShox Deluxe Ultimate RCT, 185 mm x 50 mm
Max compatible fork travel
130mm (541mm axle-to-crown)
Wheel front
Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless-Ready, 6-bolt, Boost110, 15 mm thru-axle
Wheel rear
Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, SRAM XD driver, Boost148, 12 mm thru-axle
Tyre
Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 29x2.40"
Max tyre size
Frame: 29x2.50", Fork: See manufacturer
Shifter
SRAM AXS POD Ultimate
Rear derailleur
SRAM XX SL Eagle AXS, T-Type
Crank
SRAM XX Eagle, DUB, 30T, T-Type, 55 mm chainline, 170 mm length
Bottom bracket
SRAM DUB MTB Wide, 73 m, BSA threaded
Cassette
SRAM Eagle XS-1299, T-Type, 10-52, 12-speed
Chain
SRAM XX Eagle, T-Type, 12-speed
Max. chainring size
1x: 36T round, 34T oval, min 28T
Components
Saddle
Bontrager Arvada, austenite rails, 138 mm width
Seatpost
Size:S
RockShox Reverb AXS, 100 mm travel, wireless, 34.9 mm, 340 mm length
Size:M, M/L
RockShox Reverb AXS, 150 mm travel, wireless, 34.9 mm, 440 mm length
Size:L, XL
RockShox Reverb AXS, 170 mm travel, wireless, 34.9 mm, 480 mm length
Handlebar/stem (integrated)
Size:S
Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 27.5 mm handlebar rise, 820 mm width, 0-degree stem rise, 35 mm stem length
Size:M, M/L, L, XL
Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 27.5 mm handlebar rise, 820 mm width, 0-degree stem rise, 45mm stem length
Brake
SRAM Level Ultimate 4-piston hydraulic disc
Brake rotor
Size:S, M, M/L, L, XL
SRAM HS2, 6-bolt, 160 mm
Size:S, M, M/L, L, XL
SRAM HS2, 6-bolt, 180mm
Battery
SRAM eTap battery pack (with charger)
