FrameAlloy Frame & LinkVirtual 4 link kinematic VLK29x2.6 / Boost 148x12mm UDH150mm travel / Bosch Gen4 / Integr. removable Battery1.8" Headtube, Central Kickstand MountIntegr. Cable
TravelFront & Rear: 150mm
ForkRockShox 35 TK Air15x110mm QR axle / 1.8" Tapered SteererReb. Adj. / 2 Modes / Lockout / 150mm travel / E-Bike
Rear ShockX-Fusion NUDE eRIDE TrunnionSCOTT custom w. travel / geo adj.3 modes: Lockout-Traction Control-DescendReb. Adj.Travel 150-100-Lockout / 205x55mm
Remote SystemSCOTT TwinLoc 2 TechnologySuspension & Dropper Remote3 modes
Drive UnitBosch Performance CXEU: 25kmh / INT: 20mph
BatteryPowerTube 625Wh
DisplayBosch LED Remote & Kiox 300
Charger4A Charger
Rear DerailleurSRAM NX Eagle / 12 Speed
ShiftersSRAM SX Eagle Single Click
CranksetFSA CK-745 / 165mm / 34T
Chainguidee*thirteen / e*spec Slider
ChainringSRAM Eagle 34T DM / Steel
ChainSRAM SX Eagle
CassetteSRAM PG1210 / 11-50T
BrakesSRAM DB8 4 Piston Disc
RotorSRAM Centerline CL Rotors 200mm F&R
HandlebarSyncros Hixon 2.0 Rise / Alloy 6061D.B.20mm rise / 8° / 760mmSyncros Comfort lock-on grips
H'stemSyncros AM2.0 / 6061 Alloy31.8mm / 4° / 1 1/8"
SeatpostSyncros Duncan Dropper Post 2.531.6mm / S size 125mm / M size 150mm / L size 170mm / XL size 200mm
SeatSyncros Capilano
HeadsetAcros / 1.8"ZS66 OD74 / 12mm Adapter / integr. Cable
Hub (Front)Formula CL-811 / 15x110mm
Hub (Rear)Formula CL-148S / Boost 148x12mm
SpokesStainless Black
RimsSyncros MD30 / 32H / 30mm / Pin JointTubeless ready
Front TireMaxxis Rekon / 29x2.6" / 120TPI Foldable BeadEXO+ / TR Tubeless ready3C Maxx Terra
Rear TireMaxxis Rekon / 29x2.6" / 120TPI Foldable BeadEXO+ / TR Tubeless ready3C Maxx Terra
LightsSyncros integrated rear fender lightFront Light Cable pre-installed
