Frameset
Frame
Alpha Platinum Aluminium, high main pivot, idler pulley, integrated frame protection, internal or external routing, magnesium rocker link, Mino Link, ISCG 05 2-bolt mount, Active Braking Pivot, 157x12 mm thru-axle, 200 mm travel
Fork
RockShox Boxxer Ultimate, DebonAir+ spring, Charger 3 damper, 52 mm offset, BoostDH 110x20 Maxle Stealth, 200 mm travel
Shock
RockShox Vivid Ultimate, 250 mm x 72.5 mm
Max compatible fork travel
200 mm
Wheels
Wheel front
Bontrager Line DH 30, Tubeless Ready, 6-bolt, 110x20 mm Boost thru axle, 29"
Wheel rear
Bontrager Line DH 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano 7 speed freehub, 157x12 mm thru axle, 29"
Skewer rear
Bontrager Switch thru-axle, removable lever
Tyre
Bontrager G5 Team Issue, wire bead, 2-ply 60 tpi, 29x2.50"
Rim strip
Bontrager TLR
Max tyre size
Frame: 29x2.50", Fork: See manufacturer
Drivetrain
Shifter
SRAM X01 DH, 7 speed
Rear derailleur
SRAM X01 DH, medium cage
Crank
SRAM X01 DH, DUB 83, 34T alloy ring, 165 mm length
Bottom bracket
SRAM DUB, 83 mm, BSA threaded
Cassette
SRAM PG-720, 11-25, 7-speed
Chain
SRAM PC-1110, 11-speed
Pedal
Wellgo MG-1, magnesium body, Cro-Mo axle, replaceable pins
Max. chainring size
1x: 36T
Components
Saddle
Bontrager Arvada, austenite rails, 138 mm width
Seatpost
Bontrager Rhythm Elite, 31.6 mm, 0 mm offset, 330 mm length
Handlebar
Bontrager Line Pro, OCLV Carbon, 35 mm, 27.5 mm rise, 820 mm width
Grips
Bontrager XR Trail Elite, nylon lock-on
Stem
Bontrager Line Pro, 35 mm, Direct Mount, 50 mm length
Head set
FSA Orbit, sealed cartridge bearing, 1-1/8" top, 1.5" bottom (includes geometry-adjust angled cups)
*Brake rotor
Size: R1, R2, R3
SRAM 6-bolt, 200 mm
Size: R1, R2, R3
SRAM HS2, 6-bolt, 220mm
Rotor size
Max brake rotor sizes – Frame: 220 mm, Fork: see fork manufacturer
Weight
Weight
R2 - 17.50 kg / 38.59 lbs
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
