Frame
Alpha Gold Aluminium, internal cable routing, rack & mudguard mounts, post mount disc, kickstand mount, 135x5 mm QR
Fork
FX alloy, flat-mount disc, rack mounts, 410 mm axle-to-crown, ThruSkew 5 mm QR
Hub Front
Formula DC-20, alloy, 6-bolt, 5x100 mm QR
Skewer Front
139x5 mm bolt-on
Hub Rear
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
Skewer Rear
152x5 mm QR
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve
Tyre
Bontrager H2 Comp, wire bead, 30 tpi, 700x35 mm
Max Tyre Size
700x40 mm
Shifter
Shimano U4000, 9-speed
Rear Derailleur
Shimano CUES U4000
Crank
ProWheel Pro alloy, 40T narrow-wide steel ring, 170 mm length
Bottom Bracket
Sealed cartridge, 68 mm
Cassette
Shimano LINKGLIDE LG300, 11-46, 9-speed
Chain
Shimano LG500
Pedal
Bontrager City pedals
Max. Chainring Size
1x: 44T, 2x: 46/32
Saddle
Bontrager Sport
Seatpost
Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length
Handlebar
Size: S, M Bontrager alloy, 31.8 mm, 15 mm rise, 600 mm width Size: L, XL Bontrager alloy, 31.8 mm, 15 mm rise, 660 mm width
Grips
Bontrager Satellite
Stem
Size: S, M Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length Size: L, XL Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 100 mm length
Brake Rotor
Tektro wave, 6-bolt, 160 mm
Brake Set
Tektro HD-R280 hydraulic disc, 160 mm rotor
Rotor Size
Max brake rotor sizes: 160 mm front and rear
Light
Size: S, M, L, XL Spanninga SOLO Size: S, M, L, XL AXA Greenline 35, USB rechargeable
Kickstand
Alloy, rear-mount kickstand
Cargo Rack
MIK-compatible alloy rear rack
Mudguard
Size: S, M, L, XL SKS plastic, front Size: S, M, L, XL SKS plastic, rear
Weight Limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
