Frame
OCLV Mountain Carbon, removable battery, internal routing, alloy rocker link, 34.9 mm seat tube, upper chain guide mount, 55 mm chainline, Mino Link, ABP, Boost148, UDH, 140 mm travel
Fork
RockShox Lyrik Select+, DebonAir spring, Charger 2.1 RC damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 150 mm travel
Shock
RockShox Super Deluxe Select+ RT, 205 mm x 60 mm
Wheel front
Bontrager Line Elite 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle
Wheel rear
Bontrager Line Elite 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, SRAM XD driver, Boost 148, 12 mm thru axle
Hub rear
Bontrager alloy, sealed bearing, 6-bolt, 108T Rapid Drive, SRAM XD driver, Boost148, 12 mm thru axle
Skewer rear
Bontrager Switch thru-axle, removable lever
Rim
Bontrager Line Elite 30, Tubeless Ready
Tyre
Bontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid bead, 120 tpi, 29x2.50"
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
Rim strip
Bontrager TLR
Shifter
SRAM GX Eagle AXS, 12-speed
Rear derailleur
SRAM GX Eagle AXS
Crank
E*thirteen E*spec Plus, 34T, 165 mm length
Crank arm
E*thirteen E*spec Race carbon, 34T, 165 mm length
Chainring
SRAM X-SYNC, 32T, alloy
Cassette
SRAM Eagle XG-1275, 10-52, 12-speed
Chain
SRAM GX Eagle, 12-speed
Saddle
Bontrager Arvada, austenite rails, 138 mm width
*Seatpost
Size: S
Bontrager Line Elite Dropper, 100 mm travel, MaxFlow, internal routing, 34.9 mm, 345 mm length
Size: M
Bontrager Line Elite Dropper, 150 mm travel, MaxFlow, internal routing, 34.9 mm, 440 mm length
Size: L
Size: XL
Size: XL
Bontrager Line Elite Dropper, 200 mm travel, MaxFlow, internal routing, 34.9 mm, 550 mm length
*Integrated Bar Stem
Size: S
Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 27.5 mm handlebar rise, 820 mm width, 0-degree stem rise, 35mm stem length
Size: M, L, XL
Grips
Grips
Bontrager XR Trail Elite, nylon lock-on
Brake rotor
Brake Set
Brake Set
SRAM Code R 4-piston hydraulic disc
Battery
TQ 360 Wh
*Controller
Size: S, M, L, XL
TQ LED display with Bluetooth & ANT+ connectivity
Size: S, M, L, XL
TQ handlebar-mounted
Motor
TQ-HPR50, 50 Nm, 250 watt maximum continuous rated power, 300 watt peak power
*Electronics
Size: S, M, L, XL
Size: S, M, L, XL
TQ 4A charger
Size: S, M, L, XL
SRAM AXS aux power cable
Weight
M - 18.17 kg / 40.06 lbs (with TLR sealant, no tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
